Width: 7 mm
Height: 1 mm
Length: 7 mm
Features: 50/60 Hz Rejection, Excitation Current Sources (iDACs), GPIO, Oscillator, PGA
Input Type: Differential
Resolution: 24 bit
Unit Weight: 137.400 mg
Architecture: Sigma-Delta
Sampling Rate: 780 S/s
Interface Type: SPI
Mounting Style: SMD/SMT
Reference Type: Internal
Development Kit: DEM-ADS1216
Power Consumption: 600 uW
Reference Voltage: 1.25 V, 2.5 V
Moisture Sensitive: Yes
Number of Channels: 8 Channel
Number of Converters: 1 Converter
Supply Voltage - Max: 5.25 V
Supply Voltage - Min: 2.7 V
Analog Supply Voltage: 2.7 V to 5.25 V
Digital Supply Voltage: 2.7 V to 5.25 V
Pd - Power Dissipation: 2.5 mW
Operating Supply Voltage: 2.7 V to 5.25 V
INL - Integral Nonlinearity: +/- 0.0015 % FSR
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
DNL - Differential Nonlinearity: +/- 1 LSB
