Width: 27 mm
Height: 1.78 mm
Length: 27 mm
Features: Ultra High Speed
Gain Error: 25 mV
Input Type: Differential
Resolution: 10 bit
Output Type: LVDS
Architecture: Folding Interpolating
Input Voltage: 600 mV, 790 mV, 980 mV
Sampling Rate: 1.5 GS/s
Interface Type: Parallel
Mounting Style: SMD/SMT
Reference Type: External, Internal
Sample and Hold: Yes
Power Consumption: 3.14 W
Moisture Sensitive: Yes
Number of Channels: 2 Channel
Number of ADC Inputs: 2 Input
Number of Converters: 2 Converter
Supply Voltage - Max: 1.9 V
Supply Voltage - Min: 1.9 V
Analog Supply Voltage: 1.9 V
Digital Supply Voltage: 1.8 V to 2 V
Pd - Power Dissipation: 4.4 W
Operating Supply Voltage: 1.9 V
INL - Integral Nonlinearity: 1.4 LSB
SNR - Signal to Noise Ratio: 57 dB
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
DNL - Differential Nonlinearity: +/- 0.25 LSB
ENOB - Effective Number of Bits: 9 Bit
SFDR - Spurious Free Dynamic Range: 68 dB
SINAD - Signal to Noise and Distortion Ratio: 56.1 dB
