Infrared image output
Focus manual and motor focus
Infrared resolution 320 x 240 pixel
Image refresh rate 33 Hz
SuperResolution (IFOV) 1.1 mrad
SuperResolution (Pixel) 640 x 480 pixels
Geometric resolution (IFOV) 1.7 mrad
Minimum focus distance 0.2 m
Field of view 32° x 23°
Thermal sensitivity <50 mK at +30 °C
Image output visual
Minimum focus distance 0.4 m
Image size 640 x 480 pixels
Image presentation
Display option IR image only; real image only; IR image / real image
Colours 10 (iron, rainbow, rainbow HC, cold-hot, blue-red, grey, inverted grey, sepia, Testo, iron HT)
Display type 3.5" LCD with 320 x 240 pixels
Video output USB 2.0
Measurement
Reflected temperature manual
Measuring range -20 to +100°C; 0 to +350 °C (switchable)
High temperature measuring +350 to +550 °C
Accuracy ±2 °C,; ±2% of mv / (±3% of mv at +350 to +550 °C)
Measurement
Measuring function
Surface moisture distribution Included
Humidity measurement Optional
Solar mode – manual Included
Analysis function Up to 2 measurement points, hot/cold spot recognition, isotherms, area measurement (min/max on area)
Imager equipment
Digital camera Included
Video streaming Included
Voice recording wired headset
Laser Included
Standard lens 32° x 23°
Power-LED Included
Imager storage
File format image .bmt; export option in .bmp; .jpg; .png; .csv; .xls
Storage device SD card 2 GB (approx. 1.000 images)
Power supply
Battery type Fast-charging, Li-ion battery can be changed on-site
Operating time 4 h
Charging options In instrument / charger (optional)
Mains operation yes
Ambient Condition
Storage temperature -30 °C; 60 °C
Operating temperature -15 °C; 40 °C
Housing protection class IP54
Vibration 2G
Air humidity 20 to 80 %RH non-condensing
Physical specification
Weight 900 g
Tripod mounting M6
Housing ABS
Dimensions 152 x 108 x 262
PC software
System requirements Windows XP (Service Pack 3); Windows Vista; Windows 7 (Service Pack 1); Windows 8; Interface: USB 2.0
Standards, tests, warrenty
EU-/EG-guidelines 2004/108/EG
