Infrared image output
Infrared resolution: 160 x 120 pixels
Thermal sensitivity(NETD): 100 mK
Field of view/min. focusing distance: 31° x 23° /< 0.5 m
Geometric resolution (IFOV): 3.4
testo SuperResolution (Pixel/IFOV): 320 x 240 pixels 2.1
Image refresh rate: 9 Hz
Focus:
Spectral range: 7.5 to14 µm
Visual image outputImage size /: min. focusing distance at least 3.1 MP /0.5 m
Image presentation
Image display: 8.9 cm (3.5") TFT, QVGA (320 x 240 pixels)
Display options: IR image
Data interfaces
WLAN
wireless module WLAN(EU, EFTA, USA, AUS, CDN, TR)
USB 2.0 Micro B: yes
Measurement
Measuring range:
Measuring range 1: -30 to +100 °C
Measuring range 2: 0 to +650 °C
Accuracy: ±2 °C, ±2 % of measured value
Emissivity /reflected
determination of reflected temperature (RTC)
Measurement functions
Analysis functions: Mean point measurement,
hot/cold-spot recognition, Delta T,
testo
IFOV
Imager equipment
Digital camera: Yes
Video
Storage as JPG: Yes
Fullscreen
Image storage
File format : .bmt and .jpg; export options in .bmp, .jpg,.png, .csv, .xls
Power supply
Battery
Operating
Charging options : In instrument/in charging station (optional)
Mains operation: Yes
Ambient conditions
Operating temperature range : -15 to +50 °C
Storage temperature range : -30 to +60 °C
Air
Housing protection class(IEC 60529): IP54
Vibration (IEC 60068-2-6) : 2G
Physical features
Dimensions (LxWxH) : 219 x 96 x 95 mm
PC software
System
Standards, tests
EU directive : EMC: 2014/30/EU; RED: 2014/53/EU
Optional Accessories
- Spare battery, additional
rechargeable battery for extending the
operating time.: 0515 5107
- Battery charger, desktop charging station
for optimizing the charge time.: 0554 1103
-
0554 0872
- Holster
