Temperature - NTC
Measuring range: -20 to +100°C
Temperature - TC Type K (NiCr-Ni)
Measuring range: -40 to +600 °C
Accuracy: ±0.5 °C or ±0.5 %
Absolute Pressure
Measuring range: 600 to 1150 hPa
Accuracy: ±3 hPa
Overload to 1200 hPa
Leakage measurement
Measuring range: 0 to 10 l/h
Accuracy: ±0.2 l/h or ±5 % of mv
Resolution: 10.0
Pressure measurement
Measuring range: 0 to 1000 hPa
Accuracy: ±0.5 hPa to ±3 % of mv
General technical data
Operating temperature: +5 to +40 °C
Protection class: IP40 acc. to EN 60529
Additional probe sockets: 2 Hirschmann sockets for connecting pressure and temperature probes
Gas connections: 2 pressure connections DN 5
DVGW permit according to 5925: Instrument class L up to volume = 200 litres
Storage temperature: -20 to +50 °C
Weight: 8500 g
Pipe volume calculation: max. 1200 ±0.2 or ±5 (1 to 200 l)
