Piezoelectric Accelerometer (PA-01)
Sensitivity: 5mV/(m/s²) (± 10%)
Acceleration Range: 200m/s²
Amplitude Non-linearity: ± 1%
Frequency Response: 5Hz to 10kHz (± 10%), 10kHz to 15kHz (± 3dB)
Resonance Frequency: 27kHz
Transverse Sensitivity: ≦ 5%
Dimensions/Weight: 46(H) x 19(D)mm / 46g
Measurement Range (using PA-01 or PA-02)
ACC (Acceleration): 0.02 to 200m/s² EQ PEAK 1Hz to 5kHz
VEL (Velocity):
0.3 to 1000mm/s RMS 3Hz to 1kHz
0.1 to 1000mm/s RMS 10Hz to 1kHz
DISP (Displacement):
0.02 to 100mm EQ PEAK 3Hz to 500Hz
0.001 to 100mm EQ PEAK 10Hz to 500Hz
Measurement full-scale ranges
For Accelerometer PA-01 and Accelerometer with Sensitivity: 1.0 to 9.9mV/(m/s²)
ACC (Acceleration): 1, 10, 100, 1000m/s²
VEL (Velocity): 10, 100, 1000mm/s
DISP (Displacement): 0.1, 1, 10, 100mm.
