Specifications
Piezoelectric Accelerometer (PA-01)
Sensitivity: 5mV/(m/s²)(±10%)
Acceleration range: 200m/s²
Amplitude nonlinerity: ±1%
Freqency response: 5Hz to 10kHz (±10%), 10kHz to 15kHz (±3dB)
Resonance freqency: 27kHz
Transverse sensitivity: ≦5%
Dimensoins/Weight: 46(H) x 19(D) mm / 46g
Measurement range (PA-01)
ACC (Acceleration): 0.02 to 200m/s² EQ PEAK 1Hz to 5kHz
VEL (Velocity): 0.3 to 1000mm/s RMS 3Hz to 1kHz
0.1 to 1000mm/s RMS 10Hz to 1kHz
DISP (Displacement): 0.02 to 100mm EQ PEAK 3Hz to 500Hz
0.001 to 100mm EQ PEAK 10Hz to 500Hz
Frequency range:
ACC (Acceleration): 3Hz to 1kHz, 3Hz to 5kHz, 1Hz to 100Hz, 3Hz to 20kHz
VEL (Velocity): 10Hz to 1kHz, 3Hz to 1kHz
DISP (Displacement): 1Hz to 500Hz, 3Hz to 500Hz
Measurement full-scale range:
For accelerometer PA-01 and accelerometers with sensitivity: 1.0 to 9.9mV/(m/s²)
ACC (Acceleration): 1, 10, 100, 1000m/s²
VEL (Velocity): 10, 100, 1000mm/s
DISP (Displacement): 0.1, 1, 10, 100mm
Indication characteristics:
Acceleration:: RMS, EQ PEAK
Velocity: RMS, EQ PEAK
Displacement: RMS, EQ PEAK, EQ p-p
Gain calibration (Accelerometer sensitivity selection establishes suitable gain)
Setting range: 0.10 to 0.99, 1.0 to 9.9, 10 to 99mV (m/s²)
Ambient conditions for operation
Accelerometer: -20 to +70°C, max. 90%RH
Main unit: -10 to +50°C, max. 90%RH
Manual memory: Maximum 99 data can be stored manually
Power requirements: 4 IEC R6 (size AA) batteries, AC adapter 6V (option)
Battery life (continuous use): 8 hours (approx.)
Dimensions / Weight: 158(L) × 78(W) × 40(H)mm / 286g
Supplied accessories: Instruction manual, Battery
