Bandwidth: 120 MHz
Input Coupling: DC only
Input Impedance:
10 MΩ || 2.5 pF (between inputs)
5 MΩ || 5.0 pF (either input to ground)
Attenuation: 50x / 500x
Rise Time (10-90%): 2.9 ns
Differential Voltage Range (High Attenuation):
1500 V (DC + peak AC) from 7 to 500 V/div with up to 1500V offset.
2000 V maximum typical measurable differential voltage before saturation
Differential Voltage Range (Low Attenuation): 27.6 V (DC + peak AC) from 100 mV/div to 6.9 V/div with up to 150V offset.
Common Mode Voltage Range: ±1500 V (DC + peak AC), 1000 Vrms (CAT III) (either input to ground)
Maximum Input Voltage to Earth: ±2000 Vpk (nominal, either input to ground)
Max Safe Input:
1000 Vrms CAT III
per IEC/EN 61010-031/A1:2008
Sensitivity:
100 mV/div to 6.9V/div (50X)
7V/div to 500V/div (500X)
Gain Accuracy: 1% (LF, guaranteed)
Slew Rate: 400 V/ns (maximum)
Output Coupling: AC or DC coupling
Output Termination: 1 MΩ
Interface: ProBus
Input Lead Length: 40 cm input lead length
Cable Length (input lead to oscilloscope connection): 2.25 m
