FlexChannel inputs: 4
Maximum analog channels: 4
Maximum digital channels (with optional logic probes): 32
Bandwidth (calculated rise time): 1GHz (400 ps)
ADC resolution: 12 bits
Vertical resolution: 8 bits @ 6.25GS/s
Sample rate: 6.25 GS/s on all analog / digital channels (160 ps resolution)
Record length (std.): 62.5 Mpoints on all analog / digital channels
Record length (opt.): 125, 250, or 500 Mpoints on all analog / digital channels
Waveform capture rate: >500,000 wfms/s
Arbitrary/Function Generator (opt.): 13 predefined waveform types with up to 100 MHz output
DVM: 4-digit DVM
Trigger frequency counter: 8-digit frequency counter
