General specification
Frequency range: DC – 310 MHz, 3 dB bandwidth, typical
Gain: 1:50
Rise time: ≤ 2.3 ns ( 200mV step)
RF-connectors: BNC-female
Input specification
Input impedance: 1 MΩ // 10pF
Maximum input level: max. ± 50 V for linear operation (100V differential mode)
Maximum ratings: max. ± 100 V common mode / 200 V differential mode for damage
Output specification
Output impedance: 50 Ω
Output return loss: > 20 dB, typ.
Common Mode Rejection: DC – 1 MHz > 70 dB; 1 MHz – 100 MHz ≥ 80 dB; 100 MHz – 310 MHz ≥ 50 dB
Max. output voltage: 2 Vpp
DC offset: < 10mV at output
Noise: < 1.4 mVRMS
Supply specification
Power-connector: USB-C
Indicator LEDs: Power ON
Operating voltage: 5 V DC
Current consumption: 90 mA
Operating temperature range: -20°C to +50°C
Dimensions: W 82 mm x H 33 mm x L 80 mm
Weight: 100 g
