Resistance Ranges:
1 MΩ ; 1 GΩ
10 MΩ ; 10 GΩ
100 MΩ ; 100 GΩ
All ranges include 100 % over-range capability;
minimum resistance readable is 5 % of the selected range.
Test Voltages:
50, 100, 250, and 500 VDC
50 V max. to be used with resistance < 1 MΩ
Short circuit current: < 6 mA
Accuracy*:
Test Voltages: Within ± 3 % of specified value
Resistance Value: Within ± 5 % of reading
Recommended Calibration Cycle: 1 year
Environmental:
Operating Temperature: 0 °C to 50 °C, 75 % ± 5 % RH, Non-condensing
Storage Temperature: -40 °C to 71 °C, 95 % ± 5 % RH, Non-condensing
Power and Physical:
Power: 103.5-129 VAC, 50/60 Hz
Size: 10”W x 4.9”H x 9”D
Weight: 6 lb (2.7 kg)
Included Accessories:
Test HV Cable, Test Signal Cable, Line Cord
Operator and Maintenance Manual
