TECLOCK DT-500 Dial Tension Gauge

Manufacturer: TECLOCK

Model: DT-500

Origin: Japan

Warranty: 12 months

Measuring Range: 60gf～500gf

Graduation: 10gf

Dial Reading: 60-500-60

Weight: 54 g

Catalog

 • These are mechanical tension gauges displaying in Newton, which can measure precise and moment force like tensile force or compression force

 • Miniature bearing is adopted to contact point bearing. and it can obtain stable indication accuracy.

 • It can be used for the wide range of usage for contact force such as micro-switch, relay, valve, and measuring force of dial indicator, and spring force of precise spring, and pressing force of key-board.

 • There are 2 types of standard type which sustains momentary highest value, and peak pointer type .

 • It is a multi-purpose dynamometer to use the Y head or L hooks.
