Gain: - 1 dBi, - 2 dBi, 3.8 dBi, 2 dBi, 4 dBi, 4.5 dBi, 4 dBi
VSWR: 3.5:1
Style: Chip
Width: 10 mm
Height: 1.5 mm
Length: 42 mm
Impedance: 50 Ohms
Application: Autonomous Vehicles, Smart Metering, Connected Health, Weareables, Payment Terminals
Unit Weight: 2 g
Polarization: Linear
Mounting Style: PCB Mount
Electrical Type: Embedded
Number of Bands: 7 Band
Center Frequency: 657 MHz, 700 MHz, 800 MHz, 850 MHz, 900 MHz, 1474 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2450 MHz, 2600 MHz, 3400 Mhz, 5200 MHz, 5500 MHz, 5800 MHz
Mechanical Style: Chip
Ground Plane Size: 130 mm x 42 mm
Maximum Frequency: 6 GHz
Minimum Frequency: 600 MHz
Termination Style: SMD/SMT
Moisture Sensitive: Yes
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G/5G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, UMTS, GPRS, WCDMA, HSPA
