Temperature range (*1): 5℃ above RT to +180℃
Settable temp. range (*2): -20℃ to +180℃
Temp. control accuracy (*3): ±0.1℃〜
Stirring method in Bath: Jet flow
Timer: Buzzer notification for Preset time, Operation OFF, Temp. memory interlock (= Temp. transition timer, only for SX-10N) Setting range: 1 min to 99 h 59 min (Each model)
Other functions: Digital display (switching between setting temperature and inside chamber temperature)
Timer: Buzzer notification for Preset time, Operation OFF, Temp. memory interlock (= Temp. transition timer, only for SX-10N) Setting range: 1 min to 99 h 59 min (Each model)
Other functions: Buzzer notification when preset temp. is reached, Automatic tuning, Safety device output (SM-05N is excluded. Alarm out cable AOC-2 is required to output.)
Min. Water level: 70% to 80% of Bath water capacity is maintained
Heater: 1000 W (Time proportional output variable)
Safe devices/protections: Circuit protector, Fuse, Dry-heating protection with float, Heater protection cover, Sensor error, Short circuit, High/Low temp. sample protection,Water level alarm, Nonvolatile memory error, Automatic tuning error, Alarm setting error
Power failure: Switchable Automatic/Manual recovery
Dimensions inside Bath(W×D×H): 130 × 75 × 137 mm
Main unit dimensions (W×D×H): 130 × 165 × 302 mm
Weight: Approx. 5 kg
Power supply/consumption: AC100V/11A (Need a step-down transformer), 81 Wh at 37℃ (*6)
Standard accessories: Microtube Floater × 1 pc, Plastic Water bath C-type × 1 pc (*7)
Catalog
(*1)Max. temp. may not be reached when the optional Hood is not used or depending on the usage conditions. Recommended to use our specified Heat medium for High temp (See page 134) when using tap water at high temp. as dangerous due to the steam.
(*2)Not equipped with a cooling function. Can be used together with our Chiller/Coolnit, Immersion cooler, etc. at below RT (25℃). Use our specified Antifreeze fluid (Heat medium for Low temp. See page 134) when preset temp. is below 7℃. The usage life of the components may be shortened when used at the upper limit temp.
(*3)The value under the conditions of RT (25℃), AC100 V/50 Hz, Capacity 6 liters water, Preset temp. 37℃, and No heat load. For SX-10N, this is an actual measured value (0.01 unit).
(*4)The value varies depending on the inner dia, length of the hose and hydraulic head.
(*5)The reference value when the Stainless steel Thermal insulation Water bath F-type and Optional Hood PF-SDM is used under the condition of *3. The power consumption increases by approx. 20% to 50% when the Optional Hood is not used.
(*6)The reference value when the Stainless steel Thermal insulation Water bath F-type is used under the condition of *3.
(*7)As Heat-resistant temp. of Plastic Water bath C-type is 70℃, use the Optional Stainless steel Thermal insulation Water bath.
