Temperature range/accuracy: 5℃ above RT to 50℃, ±0.2℃ (*1)
Heating method: Air Jacket type (6 Heaters)
Gas control range: CO2 : 3% to 10% (Set in 0.1%) (*2)
Gas flow rate control range: 20 to 500 mL/min (set by 1 mL/min)
Ambient temp. range: +15℃ to +35℃
Inner Dimensions(W×D×H)/Chamber volume: Chamber: 354 × 425 × 418 mm, Approx. 69 L
Example of Capacity: Up to 10 layers of Multilayer culture plate × 1 pc (*4), Erlenmeyer flask 250 mL × 6
Other functions: Connection holes (inner dia. φ30 mm)× 2 pcs, Outlet for external supply (Max. 3 A), RS-232C terminal
Gas connection port: Barbed nozzle φ9 mm (Replaceable: 1/4 Rc)
Dimensions(W×D×H)/Weight: 476 × 578 × 638 mm, Approx. 51 kg
Standard accessories: Supply tube for Culture (5 m)×1 pc, Gas supply tube (5 m)×1 pc,Hose band× 2 pcs
Power supply: AC100V/3.5A/Max.6.5A (Need a step-down transformer)
(*1)The value at the ambient temperature 25℃ and operation temperature 37℃/CO2 5%.
(*2)Measured by Infrared type CO2 sensor. (*3)Measured by Zirconia type oxygen sensor.
(*4)Please use commercially available Multilayer culture plates that are compatible with forced aeration.
•"Multi-gas" is a specification that controls CO2 and O2 Concentration by connecting CO2 Gas and N2 Gas or O2 Gas.
