Standards: ISO 8041-1:2017
Vibration Accelerations (RMS in m/s²):
1; 2; 3; 4; 5; 6; 7; 8; 9; 10 (at 79.58 Hz)
1; 2; 3; 4; 5; 6; 7; 8; 9; 10 (at 159.2 Hz)
Vibration Velocities (RMS in mm/s):
2, 4, 6, 8, 10, 12, 14, 16, 18, 20 (at 79.58 Hz)
1; 2; 3; 4; 5; 6; 7; 8; 9; 10 (at 159.2 Hz)
Vibration Displacement (RMS in µm):
4, 8, 12, 16, 20, 24, 28, 32, 36, 40 (at 79.58 Hz)
1; 2; 3; 4; 5; 6; 7; 8; 9; 10 (at 159.2 Hz)
Amplitude Error: Less than ±3 %
Frequency Error: Less than ±0.5 %
Transverse Vibration: Less than 10 % of the main direction
Harmonic Distortion:
< 3 % (at 79.58 Hz)
< 3 % (at 159.2 Hz)
General Information:
Maximum weight of calibrated object:
300 grams (at 79.58 Hz)
200 grams (at 159.2 Hz)
Power supply: Rechargeable battery 7.2 V / 2 Ah, operation time up to 12 h
Charging time: 5 hours (with SA 54) or 10 hours (with USB)
Power supply for charger: SA 54 (5 V / 1 A) or mini USB 500 mA HUB
Environmental conditions:
Temperature: from -10 °C to 50 °C (14 °F to 122 °F)
Humidity: 25 % ÷ 85 % RH, non-condensed
Dimensions: 170 × 65 × 65 mm
Weight: 1200 g (including battery)
