SUIN ST2051 ຕົວປຽບທຽບມາດຕະຖານຄວາມຖີ່ (1 CH, 5MHz,10MHz)

Measuring Channel: 1

Frequency: 5MHz,10MHz

Input Amplitude: 3dBm~13dBm,Input Impedance: 50ohm

Max.Frequency Deviation: 1×10^-8

Comparsion Uncertainty

5×10^-13/s

5×10^-14/10s

5×10^-15/100s

1×10^-15/1000s

5×10^-16/10000s

Measuring Function: Allan standard deviation,Accuracy, Booting characteristic,Aging rate,Repeatablity

Built-in Frequency Counter : 13digits/s

Port

USB:connect USB-type mouse,keyboard and USB disk

LAN:remote control

General Characteristics

Voltage: 220(1±10%)V

Frequency: 50(1±5%)Hz

Power Consumption: 65VA Max.

Working Temperature: 10~30℃

Weight: 10.5kg

Dimension: 364×155×468mm

Standard Accessories

Power Cord: 1pcs

CD(User's Guide): 1pcs

Network Cable: 1pcs

BNC testing cable: 5pcs

Connector TNC/BNC-JK: 5pcs

Feature
 With dual-channel frequency difference measuring-technique

Measuring Channel:up to 4

The sampling time could be set as user demand:1s to 108s

Graphic interface,auto and real time measurement of Allan Deviation

Measure Cesium/Hydrogen/Rubidium Atomic Clock,such as daily fluctuation,booting characteristic,aging rate,accuracy,drift,frequency deviation and difference of daily accuracy
