Measuring Function
Frequency Range
Channel 1: 1mHz-200MHz
Channel 2: 1mHz-200MHz
Channel 3: option 3GHz/6.5GHz/12.4GHz/ 16GHz/20GHz/26.5GHz/40GHz
Measurement Resolution: 11 digits/s
Period: 5ns-1000s
Time Interval Range: 1ns-10000s
Time Resolution: 25ps
Pulse Width: 1ns-10000s
Duty Cycle: 1%-99%
Totalize: 0~1×10^13
Phase Difference: 1°~359°
Input
Dynamic Range: 50mVrms~1.0Vrms (Sine), 150mVpp~4.5Vpp (Pulse)
Input Impedance: 1MΩ//35pF or 50Ω
Coupling Mode: AC or DC
Input Attenuation: ×1 or ×10
Trigger Level: -5.000V~+5.000V, min.step 1mV or auto trigger level
Other Functions
Frequency Ratio: ratio value range: 0.00001~999999
Up/Low Limit: 'Limit' light on shows the result out of range, off shows within range
Statistics Calculation: Multi-average, Max, Min, PPM, SD, Allan Variance
Standard Time Base
Daily Aging: 1×10^-8/day
Yearly Aging: 5×10^-7/year
Optional Time Base
Daily Aging: 5×10^-10/day
Yearly Aging: 5×10^-8/year
General Characteristics
Interface: RS-232, GPIB, LAN
Power
Standard: AC220V (10%), 50Hz (5%), <70VA
Dimension & Weight: 454×97.5×480mm, 7.3Kg
Standard Accessories
Power Cord: 1pcs
BNC Testing cable: 1pcs
CD(Software+ User's Guide): 1pcs
