Width: 4 mm (Max)
Height: 1.65 mm (Max)
Length: 8.75 mm (Max)
Shutdown: No Shutdown
Technology: BiCMOS
Supply Type: Single
Unit Weight: 259.200 mg
Amplifier Type: General Purpose Amplifier
Mounting Style: SMD/SMT
SR - Slew Rate: 1.3 V/us
Voltage Gain dB: 106.02 dB
Number of Channels: 4 Channel
Supply Voltage - Max: 12 V
Supply Voltage - Min: 2.7 V
Ib - Input Bias Current: 100 nA
Operating Supply Current: 1 mA
Operating Supply Voltage: 2.7 V to 12 V
Output Current per Channel: 80 mA
Vos - Input Offset Voltage: 3 mV
GBP - Gain Bandwidth Product: 4 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 9 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 60 dB
PSRR - Power Supply Rejection Ratio: 60 dB
