Width: 5.3 mm
Height: 20.3 mm
Length: 15.9 mm
Fall Time: 60 ns
Rise Time: 90 ns
Technology: Si
Unit Weight: 5 g
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 220 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 450 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 50 ns
Typical Turn-Off Delay Time: 150 ns
Id - Continuous Drain Current: 60 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 45 mOhms
Vds - Drain-Source Breakdown Voltage: 300 V
Vgs th - Gate-Source Threshold Voltage: 4.5 V
