Fall Time: 7 ns
Rise Time: 21 ns
Technology: Si
Unit Weight: 6 g
Channel Mode: Enhancement
Configuration: Single
Qualification: AEC-Q101
Mounting Style: Through Hole
Transistor Type: 1 N - Channel
Qg - Gate Charge: 46 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 284 W
Vgs - Gate-Source Voltage: - 25 V, + 25 V
Typical Turn-On Delay Time: 18 ns
Typical Turn-Off Delay Time: 46 ns
Id - Continuous Drain Current: 28 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 110 mOhms
Vds - Drain-Source Breakdown Voltage: 650 V
Vgs th - Gate-Source Threshold Voltage: 4.75 V
