STMicroelectronics L6591 Current Mode PWM Controllers PWM CONTROLLER ZVS HALF-BRIDGE

Topology: Half Bridge

Fall Time: 80 ns

Isolation: Isolated

Rise Time: 40 ns

Unit Weight: 150 mg

Mounting Style: SMD/SMT

Output Current: 1 mA

Output Voltage: 5 V

Duty Cycle - Max: 50 %

Number of Outputs: 1 Output

Moisture Sensitive: Yes

Switching Frequency: 180 kHz

Operating Supply Current: 5.3 mA

Maximum Operating Temperature: + 150 C

Minimum Operating Temperature: - 40 C
