Measuring range(mm): 300x200x200
Machine size(mm): 750*1300*1500mm
Weight（kg）: 170
Max. load（kg）: 25
Accuracy of X-Y axis (μm): 3+L/200
Repeatability（mm）: 0.003
Measuring mode：video measurement + probe
Linear encoder: exposed glass linear encoder with resolution of 1.0μm
Camera type: SBK-HC536 1/3 inches 600 lines industrial color camera
Guideway: Z axis: “HIWIN”P level guideway X-Y axis：precision cross roller guideway
Optics: 6.5:1 continual zoom detent body tube
Magnification: optics zoom ratio: 0.7-4.5X; image zoom ratio: 24-158X
Software: SBK-EP 3D measuring software
Profile illumination: LED cold lighting with 256 level programmable brightness adjustment
Surface illumination: 48 LEDs cold lighting with 256 level programmable brightness adjustment
Control system: SBK-3000 data controller、USB interface、software controlled lighting
Probe type: “RENISHAW” MCP probe system
Drive type: Manual
