SMAC VMC700B ສູນເຄື່ອງແນວຕັ້ງ

Worktable

Dimensions (mm): 800x420

T-slot Sizes (mmxN):18x3

Max Load (kg): 600

Machine range

X Axis Travel (mm): 700

Y Axis Travel (mm): 440

Z Axis Travel (mm): 530

Max distance from Spindle Nose to Worktable (mm): 660

Min distance from Spindle Nose to Worktable (mm): 130

Spindle

Taper: BT40

Speed (rpm): 8000 direct connection

Main Motor Torque (Nm): 35.8

Main Motor Power (kW): 7.5/11

Feed

X/Y/Z Axis Rapid Traverse (m/min): 32/32/32

Feed Speed (m/min): 20

Tool Magazine

Type: mechanical arm

Stations (number): 24

Changing Time (s): 2.5

Positioning Accuracy

JISB6300 (mm): ±0.005/300

JB/T8771.4 (mm): 0.012

Repositioning Accuracy

JISB6300 (mm): ±0.003

JB/T8771.4 (mm): 0.008

Gerneral Power Capacity (KVA): 18

Air-supply Pressura (Mpa): 0.5-0.7

Dimensions & Weight

Footprint (mm): 2590x2050

Height (mm): 3000

Weight (kg): 5600

CNC System: FANUC

Standard Accessories: Three-axis Ball Screw, linear guide rail X axis, linear guide rail Y axis, linear guide rail Z axis, Stainless-steel Guideway Protection, Full Enclosue, Screw-type & Water Tank Chip Conveyors, Lubricating System, Pneumatic System, Air Gun, Heat Exchanger, FANUC CNC System, SIEMENS CNC System, Ethenet, BT40 24T Mechanical Arm Tool Magazine, BT40 8,000RPM Spindle

Optional Accessories: Chain-type Chip Conveyors, Scraper-type Chip Conveyors, Magnetic Chip Conveyors, FIYANG CNC System, Renishaw NC4 Tool Detection, Renishaw TS27R Tool Detection, Marpross ML75P Tool Detection, Marpross TS30 Tool Detection, Renishaw OMP60 Workpiece Detection, Marpross E83Wa Workpiece Detection, Linear Scale, Hydraulic Monitor, Rotary Table, Air Conditioner, CE Standard
