Features: Industrial, High Electromagnetic Immunity
Shutdown: Shutdown
Fall Time: 12 ns
Rise Time: 12 ns
Logic Type: TTL
Technology: Si
Unit Weight: 508.400 mg
Configuration: High-Side, Low-Side
Qualification: AEC-Q100
Mounting Style: SMD/SMT
Output Current: 4 A
Output Voltage: 8 V
Development Kit: SI8233-KIT
Isolation Voltage: 2.5 kVrms
Number of Drivers: 2 Driver
Number of Outputs: 2 Output
Moisture Sensitive: Yes
Number of Channels: 2 Channel
Input Voltage - Max: 5.5 V
Input Voltage - Min: 4.5 V
Supply Voltage - Max: 24 V
Supply Voltage - Min: 6.5 V
Pd - Power Dissipation: 1.2 W
Propagation Delay - Max: 45 ns
Operating Supply Current: 3.5 mA
Maximum Turn-On Delay Time: 60 ns
Maximum Turn-Off Delay Time: 60 ns
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
Rds On - Drain-Source Resistance: 2.7 Ohms
