Coupling mode: Wire to wire (differential mode), wire to ground (common mode)
Surge test voltage: Up to 6kV (1.2/50us waveform)
Coupling method 1: 40Ω resistance +90V gas discharge tube
Coupling mode 2: 40Ω resistor + 0.5uF capacitor
Coupling mode 3: 40Ω resistor + special clamping device
Coupling mode 4: 90V gas discharge tube
Coupling mode 5: 0.5uF capacitor
Coupling mode 6: Dedicated clamp circuit
Surge injection interface: 4mm socket
Test product interface: 4mm socket
Terminal layout: 4-wire
Data transfer rate: 100kBit/s
Operating Voltage: Max 50V DC
Working current: Maximum 1A
Dimensions: 257mm×168mm×355mm
Weight: About 10kg
Use environment: Temperature: 10℃～35℃, relative humidity: 30%～60%
