Input:
Measuring point: 1, 2
Measuring period: 125ms
Inputs:
Direct voltage: ±10mV, 0 to 20mV, 0 to 50 mV, ±200mV, ±1V, ±10V, 0 to 5V
Thermocouple: R,S,B,K,E,J,T,C,N,PR40-20,PL,Au-Fe,U,L
RTD: Pt100, JPt100
Direct current: 4 to 20mA DC (shunt resistor: 250Ω)
Performance, characteristics:
Accuracy rating: Less than ±0.3% of rdg±3digit: Digital display, printing
Noise rejection ratio:
Normal mode rejection ratio: more than 60dB(50/60 ±0.1Hz)
Common mode rejection ratio: more than 140dB(50/60 ±0.1Hz)
Insulation resistance: Each terminal to ground terminal; More than 0.5kV DC 20MΩ
Withstand voltage:
From power terminal to ground connection terminal; 1.5 kV AC, 1 minute
From Input terminal to ground connection terminal; 0.5 kV AC, 1 minute
Vibration resistance : 10 to 60 Hz less than 1m/s²
Impact resistance: Less than 2m/s²
Alarm:
Output points: 3 points (a contact, built-in option)
Contact capacity: 250V AC 3A Max (Resistance load), 30V DC 3A Max (Resistance load)
Communication function: Type : RS-232C (Standard), RS-485 (option)
Power requirement:
Power requirement: 100 to 240V AC (50/60Hz)
Maximum power consumption:Less than 30VA (100V AC)
Architecture:
Mounting: Embeded panel, Door:dust-proof, water-jets-proof (conformity to IEC529-IP65)
Dimensions: 144W×144H×150D(mm)
Weight: Approx. 2.0 to 2.5 kg
Operation ambient: Normal operating conditions: Temperature:0 to 50°C; Humidity:20 to 80 %RH
Printing:
Recording method: Disposable felt pen
Printing method: Wire dot (1 color ink ribbon)
95% step response: Less than 1.0s
Recording paper: Length: 16m, Width:114mm, Width(folded): 40mm
Recording paper forwarding speed: From 5 to 12000 mm/h
Recording color: Red, printing color: Purple
