Gain: 2 dBi, 3 dBi, 5 dBi, 28 dB
VSWR: 1.5:0, 2:0, 3:0
Style: Dome
Length: 14.5 mm
Diameter: 84 mm
Impedance: 50 Ohms
Cable Type: 3 M RG174
Application: Cellular Applications, Wireless Applications
Unit Weight: 225 g
Polarization: Linear, RHCP
REACH - SVHC: Details
Mounting Style: Direct / Permanent Mount
Frequency Range: 698 MHz to 2.7 GHz
Number of Bands: 4 Band
Center Frequency: 700 MHz, 750 MHz, 800 MHz, 900 MHz, 1800 MHz, 1900 MHz, 2200 MHz, 2450 MHz, 2500 , 1575 MHz, 1602 MHz
Mechanical Style: Module
Maximum Frequency: 2.7 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: ISM
Antenna Connector Type: SMA Male
Protocol - GPS, GLONASS: BEIDOU, Galileo, GPS
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN, WiMAX
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, GRPS, PCS
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
