Gain: 7 dB to 8 dB
VSWR: 2.0:1
Style: Directional
Width: 147 mm
Height: 35 mm
Length: 170 mm
Frequency: 850 MHz, 900 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2600 MHz
Impedance: 50 Ohms
Cable Type: 5 M RG58
Application: Cellular Applications
Unit Weight: 499 g
Cable Length: 5 m
Polarization: Vertical
Power Rating: 50 W
REACH - SVHC: Details
Mounting Style: Bracket Mount
Frequency Range: 850 MHz to 2.6 GHz
Number of Bands: 4 Band
Center Frequency: 850 MHz, 900 MHz, 1800 MHz, 1900 MHz, 2100 MH, 2500 MHz
Mechanical Style: Log Periodic
Maximum Frequency: 2.6 GHz
Minimum Frequency: 850 MHz
Termination Style: Connector
Protocol - Sub GHz: ISM
Antenna Connector Type: SMA Female
Protocol - WiFi - 802.11: WLAN
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 30 C
Protocol - Cellular, NBIoT, LTE: 2G/3G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, GRPS, PCS
