Siretta ECHO35/0.1M/IPEX/S/S/17 ແນວຮັບສະສົມສະຕິກ 5G/4G ຂະໜາດນ້ອຍ PCB ແນວຮັບສະສົມຝັງໃນ ສາຍສັ້ນ 100MM ແລະ ຕູ້ຕໍ່ I-PEX MHF1

Gain: 2 dBi

VSWR: 2.0:1

Style: Ceramic

Width: 6 mm

Height: 0.5 mm

Length: 35 mm

Frequency: 690 MHz to 960 MHz, 1.71 GHz to 2.7 GHz

Impedance: 50 Ohms

Cable Type: 100 mm RF1.13

Application: Cellular Applications

Unit Weight: 5 g

Cable Length: 100 mm

Polarization: Linear

Power Rating: 10 W

REACH - SVHC: Details

Mounting Style: PCB Mount

Frequency Range: 690 MHz to 2.7 GHz

Number of Bands: 2 Band

Center Frequency: 700 MHz, 750 MHz, 800 MHz, 900 MHz, 1800 MHz, 1900 MHz, 2200 MHz, 2500 MHz

Mechanical Style: Patch

Maximum Frequency: 2.7 GHz

Minimum Frequency: 690 MHz

Termination Style: Connector

Protocol - Sub GHz: ISM, RFID

Antenna Connector Type: U.FL

Maximum Operating Temperature: + 75 C

Minimum Operating Temperature: - 30 C

Protocol - Cellular, NBIoT, LTE: 2G/3G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, GPRS, WCDMA
