Silicon Labs RS9113-NBZ-S1N Embedded Wireless 1band nlink Wifi BT4.0 zigbee

Antenna: Integrated

Security: WPA/WPA2

Data Rate: 1 Mb/s, 6 Mb/s, 11 Mb/s, 54 Mb/s

Frequency: 2.4 GHz

Shielding: Shielded

Dimensions: 15 mm x 14 mm x 2.1 mm

Unit Weight: 19.885 g

Output Power: 0 dBm, 8 dBm, 17 dBm

Interface Type: SDIO, USB

Mounting Style: SMD/SMT

Moisture Sensitive: Yes

Number of Channels: 2 Channel

Modulation Technique: 16-QAM, 64-QAM, BPSK, CCK, DSSS, OFDM, QPSK

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 3 V

Antenna Connector Type: u.FL

Operating Supply Voltage: 3 V to 3.6 V

Protocol - WiFi - 802.11: 802.11 a/b/g/n

Supply Current Transmitting: 500 mA

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

Protocol - Cellular, NBIoT, LTE: Cellular

Protocol - Bluetooth, BLE - 802.15.1: Bluetooth 4.0

Protocol - ANT, Thread, Zigbee - 802.15.4: ANT, Thread
