Resistance thermometers (RTD):
Generation and measurement of RTD signals : Pt50, Pt100, Pt200, Pt500, Pt1000, Cu10, Cu50, Ni100, Ni120, Ni1000
Ω-generator function : 0...3500 Ω
Ω-measurement function : 0...3600 Ω
Accuracy (of reading + const.) : ±0.012 %
Selectable temperature unit : °C / °F
Measurement of multi-wire connections : 2/3/4
Generation:
High-speed call values : 10 points (flexible)
Linear steps and ramps : ✓
User-defined synthesiser values : 10
User-defined signal output characteristic : 10 points
Editable units : ✓
Measurement:
Data memory : 10 000 values
Value tables and graphics function : ✓
Offset programming for sensor characteristic : ✓
Calibration data files and linearisation points : 5 x 4 values
User-defined measuring input characteristic : 10 points
Editable units : ✓
Measured value min. / max.: ✓
Measured value hold function : ✓
Averaging function : ✓
General data:
Features:
Sensor connection : 4 safety sockets (1 channel) incl. 2 sets with safety instrument leads (4 mm) and alligator clips (optional)
Power supply : 4 x 1.5 V AA-battery, Operating time approx. 40 h or rechargeable battery including power adapter 230 VAC / 12 VDC (optional)
PC Interface : mini-USB Type B
Operator guidance : Menu with pull-down windows, programming and control via PC
Display : Multifunction display, LCD, 6 digit
Housing:
Version : ABS plastic with protective cover
Dimensions : 160 x 85 x 45 mm (H x W x D)
Weight : Approx. 300 g
