Temperature range : -35...165 °C at ambient temperature 20 °C (-31...329 °F at ambient temperature 68 °F)
Dimension for the calibration insert : Ø 60 x 170 mm (calibration insert easily exchangeable)
Dry block Air Shield Insert : Temperature range: -30...160 °C (-22...320 °F):
External reference temperature sensor:
Display accuracy : ±0.07 °C (±0.126 °F)
Temperature stability : ±<0.001…0.005 °C (±0.0018...0.009 °F)
Temperature distribution:
+ Axial: : ±0.060 °C (±0.108 °F)
+ Radial : ±0.010 °C (±0.018 °F)
Influence of load : ±0.010 °C (±0.018 °F)
Dry block: Temperature range: -30...165 °C (-22...329 °F):
External reference temperature sensor :
Display accuracy : ±0.10 °C (±0.18 °F )
Temperature stability : ±0.005 °C (±0.009 °F )
Temperature distribution:
+ Axial: ±0.200 °C (±0.36 °F)
+ Radial : ±0.050 °C (±0.09 °F)
Influence of load : ±0.080 °C (±0.144 °F )
Internal reference temperature sensor:
Display accuracy : ±0.27 °C (±0.486 °F)
Temperature stability: ±0.010 °C (±0.018 °F)
Temperature distribution:
+ Axial: ±0.200 °C (±0.36 °F)
+ Radial: ±0.050 °C (±0.09 °F)
Influence of load : ±0.150 °C (±0.27 °F)
Calibration bath (stirred), direct filling: Temperature range: -35...155 °C (-31...311 °F):
External reference temperature sensor :
Display accuracy : ±0.19 °C (±0.342 °F )
Temperature stability : ±0.010 °C (±0.018 °F)
Temperature distribution:
+ Axial: ±0.325 °C (±0.585 °F)
+ Radial: ±0.080 °C (±0.144 °F)
Influence of load : ±0.040 °C (±0.072 °F )
Internal reference temperature sensor:
Display accuracy : ±0.24 °C (±0.432 °F)
Temperature stability: ±0.020 °C ( ±0.036 °F)
Temperature distribution:
+ Axial: ±0.325 °C (±0.585 °F)
+ Radial: ±0.080 °C (±0.144 °F)
Influence of load : ±0.200 °C (±0.36 °F)
Calibration bath (stirred), tub insert: Temperature range: -35...155 °C (-31...311 °F):
External reference temperature sensor :
Display accuracy : ±0.20 °C (±0.36 °F )
Temperature stability: ±0.010 °C ( ±0.018 °F )
Temperature distribution:
+ Axial: ±0.350 °C (±0.630 °F)
+ Radial: ±0.080 °C (±0.144 °F)
Influence of load : ±0.040 °C ( ±0.072 °F )
Internal reference temperature sensor:
Display accuracy : ±0.28 °C (±0.504 °F)
Temperature stability: ±0.020 °C (±0.036 °F)
Temperature distribution:
+ Axial: ±0.350 °C (±0.630 °F)
+ Radial: ±0.080 °C (±0.144 °F)
Influence of load : ±0.300 °C (±0.54 °F)
Infrared calibration: Temperature range: -35...165°C (-31...329 °F):
External reference temperature sensor:
Display accuracy : ±0.5 °C (±0.9 °F )
Temperature stability: ±0.020 °C (±0.036 °F)
Emission factor : 0.9994
Internal reference temperature sensor:
Display accuracy : ±0.5 °C (±0.9 °F)
Temperature stability: ±0.020 °C (±0.036 °F)
Emission factor : 0.9994
Surface calibration: Temperature range: -25...150°C (-13...302 °F):
External reference temperature sensor:
Display accuracy : ±1 °C (±1.8 °F)
Temperature stability : ±0.150 °C (±0.27 °F)
Stabilisation time (with external reference temperature sensor):
to ±0.05°C (to ±0.09 °F): From 1 min
to ±0.005°C (to ±0.009 °F): From 5 min
Heating time:
20 °C…155 °C (68...311 °F): 27 min
-35 °C…155 °C (-31...311 °F): 34 min
Cooling time:
165 °C…30 °C (329...86 °F): 17 min
20 °C…-25 °C (68...-13 °F): 35 min
Resolution of the temperature display: 0.001 °C (0.001 °F)
Hysteresis : ±0.010 °C (±0.018 °F)
Temperature units : °C / °F / K (selectable)
Reference temperature sensor: internal, fixed installation / external (selectable)
Interfaces: Ethernet, 3 x USB
Connectivity : OPC UA, HTTP. Details and further possibilities on request
Dimensions:
Width: 210 mm
Height: 380 + 50 mm (Handle)
Depth: 300 mm
Weight : Approx. 13 kg
Power supply : 100...240 VAC, 50 / 60 Hz
Power consumption : Approx. 375 W
Adjustable temperature range : -50...165 °C (-58...329 °F)
Display : Brilliant color touchscreen (7 inches), multi panel safety glass
