Workpiece
Max. Mass: 1kg
Max. rotor diameter: ø100mm
Diameter for belt drive: ø10 to ø50m
Journal diameter: ø4 to ø25mm
Span across Bearings: 35 to 200mm
Mechanical unit
Belt drive system: Upward-Tangential, Underslung, Downward-Tangential
Motor: AC servo motor, 200W
Balancing speed: 1,000 to 5,000min^-1 (Depending on outer diameter of workpiece)
Bearing support system: Soft type
Angle of unbalance index: Automatic indexing
Between bearings method: Roller bearing and/or V block bearing
Measuring unit
Min. Achievable Unbalance: 0.1 µm
Balancing plane: 1 and 2
Graphic display: 5.7" TFT color LCD with touch screen
Min. unbalance indication: 0.01mg
Indication mode
Multi-speed Multi-plane, Fix-speed Multi-plane
Polar coordinates and (3 to 99) components of unbalance vector (add or remove of unbalance correction masses are selectable)
No. of stored work data: 50 data (No limitation when use with USB memory)
Judgment of measured result: Judgment with set limit value
Data transfer: Measured data can be transferred to PC or stored USB memory -optional
Others
Power supply: single-phase AC100V 50/60Hz
Dimensions: 810(W) × 430(L) × 1,230(H)mm
Mass: Approx. 200kg (Including base frame)
