Workpiece
Max. Mass: 5kg
Max. Diameter: ø500mm
Mechanical unit
Motor: AC servo motor, 3.0kW
Chucking Adapter: Manual fitting with nuts with key
Balancing speed: 500 to 1,500 min-1
Bearing support system: Semi-hard type
Safety Cover: Double swing door with LS -optional
Vibration sensor: Optical contactless displacement sensor
Measuring unit
Balancing plane: 1 and 2 plane
Balancing method: Fixed-speed measuring
Eccentricity correction: Included
Min. Achievable Unbalance: 1.0 um
Graphic display: 5.7" TFT color LCD with touch screen
Min. unbalance indication:
Correction: 0.01mg *selecting from mg, g, kg
Unbalance: 0.01mg•mm *selecting from mm,cm
Indication mode: Polar coordinates and (3 to 24) components of unbalance vector (add or remove of unbalance correction masses are selectable)
No. of stored work data: 50 data (No limitation when use with USB memory)
Judgment of measured result: Judgment with set limit value
Data transfer: Measured data can be transferred to PC or stored USB cable
Others
Power supply: 3 phase 200V ±10%
Dimensions: 600(W) x 1100(L) x 1680(H)mm
Mass: Approx. 500kg
