SIGLENT SSA3032X-R ຕົວວິເຄາະສະເປກເວລາຈິງ (9kHz~3.2GHz)
Frequency range: 9kHz~3.2GHz
Resolution bandwidth: 1Hz~3MHz
Displayed average noise level: -165dBm/Hz
SSB phase noise: <-98 dBc/Hz
Total amplitude accuracy: <0.7dB
Tracking generator: 100kHz-3.2GHz
Real-time bandwidth: 25MHz, 40MHz (Option)
RTSA SFDR: 60dB
RTSA Measurement: Density, Spectrogram, 3D, PvT
VNA measurement: Vector S11, Vector S21
VNA dynamic range: 90dB
Touch screen: Multi Touch, Mouse and Keyboard supported
Advanced measurement: CHP, ACPR, OBW, CNR, Harmonic, TOI, Monitor
Communication interface: LAN, USB Device, USB Host (USB-GPIB)
Standard accessories:
Quick Start
USB cable
Power cord
Optional accessories
Advanced Measurement Kit: SSA3000XR-AMK
Utility Kit: UKitSSA3X
N(M)-SMA(M) cable(6 GHz), N(M)-N(M) cable(6 GHz),
N(M)-BNC(F) adaptor x2, N(M)-SMA(F) adaptor x2,
10 dB 1W attenuator
N(M)-SMA(M) cable, 70cm, 6GHz: N-SMA-6L
N(M)-N(M) cable, 70cm, 6GHz: N-N-6L
N(M)-BNC(M) cable, 70cm, 2GHz: N-BNC-2L
N(M)-SMA(M) cable, 100cm, 18GHz: N-SMA-18L
N(M)-N(M) cable, 100cm, 18GHz: N-N-18L
USB-GPIB Adaptor: USB-GPIB
Soft carrying bag: BAG-S2
6U Rack Mount Kit: SSA-RMK
