Channel:
- CH1 output voltage: 0~32V, output current: 0~3.2A
- CH2 output voltage: 0~32V, output current: 0~3.2A
- CH3 output voltage: 2.5/3.3/5.0V, output current: 3.2A
Display:
- 4.3 inch true color TFT-LCD
- 5 digits voltage 4 digits current
Resolution: 1mV/1mA
Program accuracy:
- Voltage ±(0.03% of reading+10mV)
- Current ±(0.3% of reading+10mA)
Readback accuracy:
- Voltage ±(0.03% of reading+10mV)
- Current ±(0.3% of reading+10mA)
Constant voltage mode
- Line Regulation: ≤0.01%+3mV
- Load Regulation: ≤0.01%+3mV
- Ripple&Noise: ≤1mVrms (5Hz~1MHz)
- Recovery time: <50μs (50% load change, minimum load 0.5A)
Constant current mode
- Line Regulation: ≤0.2%+3mA
- Load Regulation: ≤0.2%+3mA
- Ripple&Noise: ≤3mArms
CH3
- Output voltage: (2.5/3.3/5V) ±8%
- Line Regulation: ≤0.01%+3mV
- Load Regulation: ≤0.01%+3mV
- Ripple&Noise: ≤1mVrms (5Hz~1MHz)
Max output power: 220W
Power source: AC 100V/120V/220V/230V ±10% 50/60Hz
Standard configuration interface: USB Device, LAN
Dimension: 225(W)×143(H)×278(D)mm
Weight: ≈8.0kg
Standard accessories
USB Cable: 1
Quick Start: 1
Calibration Certificate: 1
Power cord: 1
Output test Cord: 2 Sets
