SIGLENT SNA5004A Vector Network Analyzer (9kHz~4.5GHz; 4 ports)
ຜູ້ຜະລິດ: SIGLENT Model: SNA5004A ຮັບປະກັນ: 12 Tháng - ຕິດຕໍ່ພົວພັນ
Frequency range: 9kHz-4.5GHz
Ports: 4
Frequency resolution: 1Hz
Level resolution: 0.05dB
Range of IFBW: 10Hz~3MHz
Setting range of output level: -55dBm~+10dBm
Dynamic range: 125dB
Bias-Tees: Support
Interface: LAN, USB Device, USB Host(USB-GPIB)
Remote control: SCPI/Labview/IVI based on USB-TMC/VXI11/Socket/Telnet/WebServer
Display: 12.1-inch touch screen
Video output: HDMI
Standard accessories
One Quick-start
One Power-cable
One USB-cable
One calibration-certificate
Optional accessories
High-performance reference source: SNA5000-HPR
Time-Domain analysis: SNA5000-TDA
Enhanced Time-Domain analysis: SNA5000-TDR
N-type, Male, 50Ω Calibration Kit, 0-4.5GHz: F503ME
N-type, Female, 50Ω Calibration Kit, 0-4.5GHz: F503FE
3.5mm, Male, 50Ω Calibration Kit, 0-4.5GHz: F603ME
3.5mm, Female, 50Ω Calibration Kit, 0-4.5GHz: F603FE
N-type, Male, 50Ω Calibration Kit, 0-9GHz: F504MS
N-type, Female, 50Ω Calibration Kit, 0-9GHz: F504FS
N-type, Male and Female, 50Ω Calibration Kit, 0-9GHz: F504TS
3.5mm, Male, 50Ω Calibration Kit, 0-9GH: F604MS
3.5mm, Female, 50Ω Calibration Kit, 0-9GHz: F604FS
3.5mm, Male and Female, 50Ω Calibration Kit, 0-9GHz: F604TS
