Transfer rate: 10 Mbit/s, 100 Mbit/s
Interfaces
Number of electrical/optical connections / for network components or terminal equipment / maximum: 5
Number of electrical connections
for power supply: 1
for redundant voltage supply: 1
Type of electrical connection
for power supply: 5-pole terminal block
Design of the removable storage / C-PLUG: Yes
Signal inputs/outputs
Number of electrical connections
for digital input signals: 1
for digital output signals: 1
Type of electrical connection
for digital input signals: 2-pole terminal block
for digital output signals: 2-pole terminal block
Supply voltage, current consumption, power loss
Type of voltage / 1 / of the supply voltage: DC
Supply voltage / 1 / rated value: 24 V
Power loss [W] / 1 / rated value: 4 W
Supply voltage / 1 / rated value: 10.8 ... 28.8 V
Consumed current
at DC / at 24 V / typical: 0.2 A
product component / 1 / fusing at power supply input: Yes
fuse protection type / 1 / at input for supply voltage: Non-replaceable melting fuse (F 2 A5 / 32 V)
Ambient conditions
Ambient temperature
during operation -40 ... +70 °C
during storage -40 ... +80 °C
during transport -40 ... +80 °C
Relative humidity / at 25 °C / without condensation / during operation / maximum: 95 %
