Application: Indoor
Reading field: Front
Light source: Visible red light (660 nm)
Laser class: 2 (IEC 60825-1:2014, EN 60825-1:2014)
Aperture angle: Horizontal 70°
Scanning frequency: 600 Hz
Angular resolution: 0.0833°
Working range: 0.7 m ... 3 m
Scanning range: At 2% remission 2.3 m / At 3,5% remission 3 m / At 10% remission 3 m
Connection type: 1 x M12, 5-pin plug (Power + I/O + Sync) / 1 x M12, 8-pin female connector (Ethernet) / 1 x M12, 5-pin female connector (Encoder + I/O)
Supply voltage: 24 V DC, ± 25 %
Power consumption: ≤ 16 W, start-up phase max. 29 W
Output current: ≤ 100 mA
Housing: Aluminum die cast
Housing color: Light blue (RAL 5012)
Tiêu chuẩn: IP65
Protection class: III
Electrical safety: IEC 61010-1:2011
Trọng lượng: 2.4 kg
Dimensions (L x W x H): 192 mm x 130 mm x 107 mm
Ethernet: ✔, TCP/IP, UDP/IP
Digital inputs: 2
Digital outputs: 3
Synchronization inputs/outputs: One (master / slave)
