Input signal: 4 to 20mA (with zero and span fine adjuster)
Input resistance: 10Ω
Display range: * Can be set from 0 to any full scale value
Display: 7 segment red LED 5 digits
Sampling period: * Can be set to 0.1/0.2/0.5/1/2/3/4/5 seconds Standard is 1 second
Accuracy: ±0.3%±1digit (23℃±5℃)
Converter drive power supply: +24V DC, 50mA max
Alarm setting: Upper limit of AL I and AL II can be set arbitrarily.
Automatic reset/self-holding possible.
Checking alarm values: The set value is displayed by pressing the ALⅠ or ALⅡ key.
Alarm relay: Each 1C contact
Rated AC250V, 5A DC30V, 5Amax (resistive load)
Alarm delay: * Arbitrary setting from 0.1 to 99.9 seconds Standard is 5 seconds
Analog output (OP): 4 to 20mA, 0 to 5V, 1 to 5V, 0 to 10V can be ordered
Power supply: AC85～264V 50/60Hz 15VAmax (Optional DC24V available)
Operating temperature/humidity: 0 to 50°C 85% RHmax (no condensation)
Mass: about 300g
