Applicable fiber: SM(ITU-T G.652), MM(ITU-T G.651), DS(ITU-T G.653), NZDS(ITU-T G.655)
Diameter of cladding: 80 -150μm
Diameter of coating: 160-3000μm
Typical splice loss: SM: 0.02dB, MM: 0.01dB, DS: 0.04dB, NZDS: 0.04dB
Return loss: ＞ 60dB
Fibe cleaved length: 5-16mm ( coating diameter ＜ 250um), 16mm (coating diameter: 250-1000um)
Splicing program: 40 groups
Operate mode: Automatic/Manual
Auto-heating: Available
Typical splicing time: 7 seconds
Typical heating time: 26 seconds
Fiber magnification: 320X (X or Y view), 160X (X and Y view)
Display screen: 4.3 inch color LCD monitor
Records storage: 8000 results
Loss evaluation: Available
Tension test: 1.8-2.2N
Interface: GUI menu interface, easy for operation
Battery: 5200mAh Li-battery, typical 250 cycles splicing and heating
Power supply: Adapter, input: AC 100-240V(50/50HZ), output: 11-13.5V
Electrodes life: More than 4000 ARC discharges, can be replaced vonveniently
Ternimal: USB2.0 port, for software upgrading and records exporting
Operating conditions: Altituede: 0-5000m, Humidity: 0-95%, Temperature: -10℃~+50℃, Wind speed: Max 15m/s
Dimension: 149mm(L) * 120mm(W) * 127mm(H)
Weight: 1.90kg (including battery)\
