Alignment method: Clad to clad
Applicable fiber: SM(G.652),MM(G.651),DS(G.653),NZDS(G.655)
Cladding diameter: S-27-250: 125~250µm; S-27-400: 250~400µm
Coating diameter: 250~1000µm
Typical splice loss: SM: 0.02dB; MM: 0.01dB; DS: 0.04dB; NZDS: 0.04dB
Return loss: >60dB
Splicing program: 40 groups
Operation mode: Manual/ Automatic
Auto- heating: Available
Typical splice time: 14seconds
Typical heating time: 24 seconds for 60mm/40mm heating tube
Fiber magnification: X or Y single fiber image 120X,X and Y double image 60X
Viewing display: Dualhighsensitivitycamera, 5 inch 800*480 LCD Monitor
Data storage: 4000 groups data records and 100 group images
Loss evaluation: Available
Tension test: 1.8~2.2N
Interface: GUI menu interface, easy for operation
Power supply: Adaptor, input: AC100-240V(50/60HZ),output: DC11-13.5V
Electrode life: >3000 times discharge (125um),>1000 times discharge (>125um)
Terminals: Micro-USB 2.0 port, forsoftwareupgrading, records exporting
Operating condition: Altitude: 0-5000m, Humidity: 0-95%, Temperature: -10℃~+50℃; Wind: max 15m/s
Dimension: 155mm (L)×144mm (W)×155mm (H)
Weight: 2.3kg (including battery)
