Alignment Method: Core to core
Cladding Diameter: 125 to 500um
Coating Diameter: 250～800µm
Splicing Program: 40 groups
Operation Mode: Manual/ Automatic
Applicable Fiber: SM (ITU-T G652),MM( ITU-T G651),DS( ITU-TG653),NZ-DS,EDF,DCF,LDF
Typical Splice Loss: ITU-T G652:0.03dB; ITU-T G651: 0.02dB; ITU-T G653:0.05dB
Auto- Heating: Available
Typical Splice Time: 35 seconds for 400um cladding
Typical Heating Time: 30 seconds typical
Fiber Magnification: 100~200X adjustable
ViewingDisplay: Dual high sensitivity camera, 5 inch color LCD Monitor
Data Storage: 8000 groups data records and 200 group images
Cleave Length: 13-15mm (NOM:13mm)
Tension Test: 30N(Use high-strength welding accessories and coating for clamping)
Interface: GUI menu interface, easy for operation
Power Supply: Adaptor, input: AC100-240V(50/60HZ), output: DC12V
Electrode Life: ＞3000 times discharge (125um),＞1000 times discharge (＞125um)
Terminals: Micro-USB 2.0 port, for software upgrading, records exporting
Electrode Spacing: 125µm:1.0mm, 250µm--500µm:3mm
Dimension/Weight : 330*205*170mm/4.1kg (including battery)
Standard Package:
S-37LDF main machine: 1 unit
Fiber Holders: 1 unit
Electrodes: 1 unit
Power Adapter: 1 pc
Power Cord: 1 pc
USB Manual: 1 pc
Carrying Case: 1 pc
