Fiber Type: SMF (G.652), MMF (G.651), DSF (G.653), NZ-DSF (G.655), BIF (G.657), CSF (G.654), EDF
Protection Sleeve: 40mm - 60mm
Splicing Principle: Arc
Alignment: 4 Motors Alignment
Splice Control: Auto and Manual Splicing
Arc Optimization: Yes
Splice Mode: 240 groups
Heating Mode: 60 groups
Display Mode: X, Y, X+Y
User Interface: Graphical interface, multiple language support
Splice Result: Auto splice result (Loss) calculation and display
Data: ≥10000 splice records (CSV format), ≥150 screenshots
Data Port: USB, Driver-free
Fiber Diameter: Cladding: 80~150μm, Coating: 100~1000μm
Cleave Length: 5mm~16mm
Splice Loss: MMF ≤ 0.01dB (Typical), SMF/BIF ≤ 0.02dB (Typical),
: DSF/NZDSF/EDF ≤ 0.04dB (Typical), CSF ≤ 0.02dB (Typical)
Return Loss: >60dB
Splice Time: ≤6s (Fast mode), ≤9s (Auto mode);
Heating Time: ≤18s, Adjustable
Zoom: 400 x（X+Y）； 320 x (X or Y)
Electrode Life: ≥5000 splices
Tension Test: 1.96N～2.25N
Start-up Time: ＜10s
Power Supply: 220V±10%, 50Hz AC/DC; Rechargeable Lithium Battery；support operation when charging
Battery Life: ≥200 Splicing and Heating
Chanrging Time: ≤4 hours
Size: 131mm×79mm×200mm (L x W x H)
Weight: 1.3Kg (With Battery)
Work Temperature: -20℃～+55℃
Storage Temperature: -40℃～+70℃
Humidity: ≤95% (non-condensing)
Altitude: 0 m～5000 m
Wind Speed: ≤15 m/s
