Sew ST-75 Switchboard Multi-Electric Meter ( 2% DC, 2% AC, 2.0% Frequency)

Accuracy: 2% DC, 2% AC, 2.0% Frequency

General Dimension: 76 x 58 mm

Hole Diameter: Ø53.5

Is a T-series Products

Note: Select the device following this measuring ranges:

For DC:

- µA Scale: 50, 100, 150, 200, 250, 300, 500

- mA Scale: 1, 5,10,20, 50,100, 150, 200,250, 300,500

- A Scale: 1, 1.5, 5, 10, 20

- mV Scale: 50, 60, 100, 500

- V Scale: 3,5,10,20, 30, 50,100,150, 200,300,500

For AC:

-V Scale: 30,50, 100, 150, 200,300, 500

For Frequency: 45~55Hz ; 45~65Hz; 55~65Hz
