Test voltage (DC V) : 250V / 500V / 1000V
Output voltage @ 1mA : Rated test Voltage +10% Max
Measuring ranges : 0.2M~2G / 0.2M-4G / 0.2M-8GΩ
Accuracy : 0.2M~4GΩ : ±3%rdg
4GΩ~8GΩ : ±5%rdg
Continuity Test
Measuring ranges : 0.01-1999Ω
Accuracy : 0.01-100Ω : ±1.0%rdg
100-300Ω : ±1.5%rdg
300-1999Ω : ±2.0%rdg
Voltmeter
AC voltage (Auto) : 0-700V
DC voltage (Auto) : 0-950V
Accuracy : ±1.5% rdg
Resolution : ±1V
MOV Test & GAS Arrester Test
Test voltage 5-1020Vdc
Voltage result accuracy ±3% rdg
Voltage result resolution ±2 counts
Protections
Over load : 700V (between all terminals)
Over voltage : Class III-700V towards ground
General
With PI and DAR : test function 10Min
Load battery test current : About 300mA
Dimensions : 250(L) × 190(W) × 110(D)mm
Weight (battery included) : Approx 1460g.
Power source : 1.5V(AA) × 8
Safety standard :EN 61010-1 CAT III 600V
EN 61326-1
Accessories : Instruction manual,Test leads Shoulder belt, Batteries
