Switch: without
Nominal width: DN 32
Process connection: female thread G 1 1/4
Switching range: 10 - 60 l/min
Pressure loss: ~1 bar at Qmax
Qmax.: to 300 l/min
Tolerance: ±10 % of full scale value
Pressure resistance: PS 200 bar
Media temperature: -20..+120 ℃
Ambient temperature: -20..+70 °C
Media: water
Materials medium-contact
Brass construction: CW614N nickelled, CW614N, 1.4305, 1.4310, hard ferrite
Non-medium contact materials: CW614N nickelled, PC, acrylic
Weight see table "Dimensions and weights"
Installation location
Standard: horizontal inwards flow from the left; other installation positions are possible; the installation position affects the switching point and range.
