Version: Device with fix mounted cable and sensor protection sleeve, exchangeable sensor, MOD-calc. NITROX
Set-Option: Instrument, battery, manual, ESA 369 + ZOT 369, suitcase GKK 252
Connections: Thread M16x1, 3.5 mm audio plug socket
Dimensions: 108 x 54 x 28 mm (H x W x D) excl. sensor
Display: 3-line with battery status indicator, Backlight, protected by shatterproof screen, overhead display at the push of a button
Housing material: break proof ABS, screw locked battery compartment
Measurement rate: 1 meas/s
Measuring range: Oxygen concentration:
ECO 410-35: 0.0 ... 100.0 vol. % O₂, recommended for 0.2 ... 35 % vol. % O₂ (reduced precision beyond)
Standard for gas at sport diving, protection gases at raised CO2 levels and may more
Resolution: 0.1 vol. % O₂
Nominal temperature: 25 °C
Operating conditions: 0..+45 °C; recommended 5..+30 °C: optimized temperature compensation in this range: 0..+95 % r.H. (short time condensing)
Power supply: 2*AA batteries (included), operating time > 3000 h ; 4 level battery status indicator,
Low battery indication: "BAT LO".
Auto power off: function, configurable; Precision adjusted to ambient air, constant conditions for measurement ECO 410-35:
Sensor:
GOEL 370:
< 35 vol. % O₂: -0.2 … +0.35 vol. % O₂ 35…100 vol. % O₂: not specified
Sensor life time at 20.9 vol. % O2 ca 2 years
Protection type: IP65 / IP67, Sensor IP54
Response time: 90% in < 10 sec., depending on temperature
Sensor Cable: 0.95 m, audio plug, elastic sensor protector
Storage temperature: -20..+50 °C
Weight: 175 g incl. sensor
Cable length: 0.95 m PVC cable with 3.5 mm sensor plug
Current supply: 2 x AA batteries
Sensor: GOEL 370: 0 ... 100 % Vol. O₂, recommended 0.2 ... 35 Vol.-% O₂ (beyond reduced precision)
Working temperature: 0 ... 45 °C
