Frequency range: 30 MHz … 118 MHz
Maximum operating current: 16 A
Maximum operating voltage: 265 VAC @ 50/60 Hz
Differential mode impedance: 100 Ω ±20% (30 MHz – 87.5 MHz)
Differential attenuation: 40 dB ±4 dB (1.6 MHz – 87.5 MHz)
Common mode impedance: 50 Ω +30% / ‑10% (30 MHz – 118 MHz)
Measurement port: 2 × BNC (female), 50 Ω
Voltage division factor EuT(diff. mode) - measurement port (common mode): typical 5.7 dB ±0.5 dB
Housing material: Aluminium
Dimensions: 445 mm × 145 mm × 470 mm
Weight: 8 kg
Connectors EuT, CS: 4 mm safety laboratory jacks
Ground connectors: bottom of case, 4‑mm lab jack, aluminium bracket at rear side
